small size furniture baking oven/ infrared heater furniture body paint booth with dry filter


Price: Negotiable
Order: 0
Total amount: 0
Delivery period: From the date of payment by the buyer 3 shipped within days
Valid until: long term effective
latest update: 2020-01-10 14:15
Browse times: 107

COMPANY BASIC INFORMATION
Detailed description

Quick Details
Type:
Spray Booths
Place of Origin:
Shandong, China
Brand Name:
BLUESKY
Voltage:
380v/50hz/3ph
Certification:
CE
Internal Size:
6000x5000x3000 painting room
External Size:
12000x5000x3000mm
Warranty:
2 Years
Name:
furniture baking oven
Painting Room Dimension:
6000x5000x3000mm
Drying Room Dimension:
6000x5000x3000mm
Baking method:
Electrical Infrared Lamp
Infrared Heating Tubes:
24x1kw infrared light heater
Wall panel:
50mm EPS
Filters:
air-intake pre-filter, ceiling filter, water curtain filter
Color:
cutomer request
Useage:
furniture body paint booth
Keywords:
furniture Paint Booth
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
In standard export packing, packed in 40 GP container.
Port
Qingdao
Picture Example:
package-img

package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 To be negotiated

Product Description
Notes: We can produce the color and size as your request!
Model
60 M2
Outside Dimension(mm)L×W×H
12000x5000x3000
Painting Room Dimension(mm)L×W
6000x5000x3000
Drying Room Dimension(mm)L×W
6000x5000x3000
Incoming Door Dimension(mm)W×H
1900×2300
Delivery Door Dimension(mm)W×H
1900×2300
Air Capacity(m3/h)
20000
Air Speed(m/s)
0.2-0.3
Ventilation Rate(Times/Hour)
255
Fan Power(KW)
2*1.5kw   2*2.2KW
Wall Panels
Panels 50mm EPS colorful steel skin panel,
steel 0.4mm thick,12kg/cbm and flame-resisting EPS,
tongue groove style, compound construction, anti-flame and heat-insulation.
Grilles
10#channel steel, 6M2
Lighting
4*4*36W lamp,Illuminance exceeding 750LUX, non explosive
Infrared Heating Tubes
24 pieces ×1 KW infrared light heater ,anti-explosion
Generator Setting Type
Upper intake air
Intake Air Fan For painting room
2×1.5KW double-intake centrifugal fans, air capacity: 20000m³/h
Exhaust Fan For painting room
2×2.2 KW with water curtain booth.
Filter System
Intake air: pre-filter, high efficiency filter(ceiling filter)
Exhaust air: water curtain filtering
Water Curtain
Water curtain painting table features: It can directly spray the paint powder remaining in the painting time in the pool or water curtain surface, and the odor generated during painting and the hourly paint powder are filtered by the multi-layer water curtain and discharged to the painting through the exhaust fan. Outside the room, it can purify the working environment of the paint and protect the health of the person, and can enhance the surface finish of the painted workpiece.
  • Infrared Heating System

24 pieces ×1 KW infrared light heater ,anti-explosion
Lighting
4*4*36W lamp,Illuminance exceeding 750LUX, non explosive
AIr-outlet fans
2x2.2kw Exhaust fans with water curtain for painting room.
Sliding door
Between the painting room and  drying room, there is a sliding door, convenient for wooden working.
Packing&Shipping
Customers Feedback
After Sales Service
Our Service
1. OEM ODM service.
2. Customized service: The color and size of the product can be customized.
3. One Year Quality warrant service, during the period spare part supplied free if you pay for shipping.
4.Professional team supply service for life long time.
Company Introduction
Shandong Lantian Huaer Environmental Protection Equipment Co.,Ltd is professional auto maintenance equipment manufacture since
2000
with brand “BLUESKY”, in Chinese Lantian means Bluesky.
Our factory covers an area of more than 2,500 squares metters and with our up-today manufacturing facilities, high tech
industrial, product developing manufacturing sales and perfect after-service with total capital of more than ten millions.
For many years our copany have been awarded as”Enterprise with high reputation” ”Enterpris with high credit in quality” and “China
national grade AAA enterprise” ....etc. Besides, we have passed ISO9001, authenticated by 2000 international quality control
system.
Customer Photos
FAQ
1, Are you manufacturer or trading company?
We are manufacturer, welcome to visit our factory, located in Zoupin, Shandog provine, China
2,Can you make my own Logo on it?
Yes, we can do OEM service. We can produce the color, size, logo as your request.
3, How to buy it?
After confirm all the details, we will draft an Alibaba trade assurance order for you, then you can pay by T/T or Credit Card.
Alibaba 100% ensures your right and Financial security.
4, What is the delivery time?
One sets needs about 15 days for production, then we book shipping for you, it takes about 30 days to arrive by sea.
5, What does the package?
In standard export packing, packed by 40 HQ/GP container.
6, Do you have after-sale service?
Yes, spray booth is warranted for Two years. During this time, any spare parts damage by quality, we are responsible to send a new one, the DHL fees is borne by customers.
