High quality Steel Plastic Composite Geogrid
Feicheng Lianyi Engineering Plastics Co., Ltd. is a comprehensive enterprise. Our business scope covers scientific research, development, manufacturing and sales of geosynthetic, plastic and fiberglass products.
At present, our company owns fixed assets of RMB800 million, with 581 staff members, 48 percent of who are graduated from domestic universities. We also have established long-term cooperation relationships with several research institutes, universities and designing institutes. Our technical capability is very abundant. Our annual output is about 150000 tons.
Our leading products are chopped strand mats, E-glass chopped strand mats, C-glass chopped strand mats, fiberglass geogrids, polyester gegorids, geogrids, geonets, geocells, safety fences, warp-knitted geogrids, steel welded geogrids and geo-mattress. They have been widely used in the fields of highway, railway, reservoir, airport and mine.
Our company is also one of the earliest members of China Geosynthetic Material Engineering Institute. We have obtained ISO9001 and CE certificates, and some products have passed SGI test.
Now our products have been sold to many countries and areas, such as Korea, Israel, Kuwait, Thailand, Canada, Panama, and Taiwan area, winning a good reputation.
Providing high quality and perfect service for consumers is our management theory. Keep innovating and constantly improving our products is our developing policy. We are looking forward to establishing long-term cooperation relationship with you.
Steel plastic composite geogrid
Production Intruction
The steel plastic composite geogrid uses high tensile steel wire (or other fiber)specially handled and polyethylene(P.E)with other assistants. Then squeeze it out and make it become composite high-strength anti-pull belt and the surface has rough embossing then it is reinforcement earthwork belt.Warp knitting vertically and horizontally using this single belt and welding the joint using a special welding techology to molding is reinforcement geogrid.
Product Features
1.The intensity is high and the distort is small;
2.The wriggle is small;
3.Anti-corrosive,the life is long,the geogrid take the plastic material as a protector, auxiliary enables it by each kind of assistant to have the antiaging,the oxidation susceptibility again,but acidproof ,alkali,salt and so on adverse circumstance corrosion.Therefore ,the steel modles the earhwork gril to be possible to meet each kind of permanent work100year above use need,and the perfor mance is superior,the size stability is good;
4.The construction is convenient ,the cycle is quickly short.the cost is low;the steel plastic complex geogrid to lay down,joining ,the localization to be easy,to be smooth,avoids overlapping crossover,but reduced the project cycle effectively,saved the building cost of projects by 10%-50%.
Production Function
Steel Plastic Geogrids are applied widely in railway,bridge,dock,retaining wall.dam to reinforce the soft soil and to resist the road surface's crack.
| Product specifications and performance parameters | ||||||||||
| High-strength steel plastic uniaxial(Vertical) geogrid | ||||||||||
| Project | TGDG30 | TGDG50 | TGDG80 | TGDG100 | TGDG120 | TGDG150 | ||||
| Vertically Limited-Rally (kn/m)≥ | 30 | 50 | 80 | 100 | 120 | 150 | ||||
| Vertically Limited elongation ratio (%)≤ | 3 | 3 | 3 | 3 | 3 | 3 | ||||
| Elongation at 1% of the Rally (kn/m)≥ | 23 | 38 | 63 | 81 | 98 | 125 | ||||
| High-strength steel plastic biaxial(Vertical and horizontal) geogrid | ||||||||||
| Project | TGSG30-30 | TGSG45-45 | TGSG60-60 | TGSG80-80 | TGSG100-100 | TGSG120-120 | ||||
| Two-way Limited-Rally (kn/m)≥ | 30 | 45 | 60 | 80 | 100 | 120 | ||||
| Two-way Limited elongation (%)≤ | 3 | 3 | 3 | 3 | 3 | 3 | ||||
| Elongation at 1% of the Rally (kn/m)≥ | 23 | 36 | 48 | 63 | 81 | 98 | ||||
Other Geogrids;
Products with CE Certificate,Welcome choose us!
Please do feel free to contact us for more product information !
