OEM 30 W poly crystalline solar panel


Price: Negotiable
Order: 0
Total amount: 0
Delivery period: From the date of payment by the buyer 3 shipped within days
Valid until: long term effective
latest update: 2020-06-09 17:38
Browse times: 131

COMPANY BASIC INFORMATION
Detailed description
 Quick Details
seline; color: rgb(51, 51, 51);">
Place of Origin:
Shandong, China
Brand Name:
JOYSOLAR
Model Number:
JYSP-30P
Type:
BIPV
Size:
670 mm * 350 mm * 30 mm
Panel Efficiency:
21
Certificate:
CE
Warranty:
25 Years
Product name:
Poly Crystalline Solar Panel
Cell Technology:
Poly-Si
Out Put Power(Pm):
30 ± 5% W
Max.Power Voltage(Vmp):
18.61 V
Max.Power Current(Imp):
1.61 A
Open Circuit Voltage(Voc):
22.37 V
Short Circuit Current(Isc):
1.78 A
Weight:
2.6 KGS
Max System Operating Voltage(V):
1000 V
Encapsulation:
Glass/EVA/Cells/EVA/TPT
seline; color: rgb(51, 51, 51);">
Product Certification certification
 CE Certified.
Valid from 2019-08-21 until 2024-08-21
seline; color: rgb(51, 51, 51);">
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
seline; color: rgb(51, 51, 51);">
Packaging & Delivery
Packaging Details
Two panels in one carton, and the outdoor packing is wooden box.
Port
Qingdao, CHINA
Picture Example:
package-img

package-img
Lead Time :
Quantity(Watts) 1 - 3000 >3000
Est. Time(days) 15 To be negotiated
Specification
MODEL
JYSP-30P
JYSP-50P
JYSP-60P
Pmax
30 W
50 W
60 W
Tolerance
+/-5%
Vmp
18.61 V
18.13 V
19.43 V
Imp
1.61 A
2.76 A
3.10 A
Voc
22.37 V
22.61 V
22.97 V
Isc
1.78 A
2.95 A
3.26 A
Encapsulation
Glass/EVA/Cells/EVA/TPT
Size
156 * 52 / 156 * 66
Max.syst.Oper.Voltage V
1000 VDC
Dimension
                          670 * 350 * 30 mm/670 * 540 * 30 mm/670 * 645 * 30 mm
Weight kg
2.6 KGS / 3.8 KGS / 4.5 KGS
Operate Temp. Scope
-40/85℃
Relative humidity
0 to 100%
Resistances
227g steel ball fall down from 1m height and 60m/s wind
Warranty
Pm is not less than 90% in 10 years and 80% in 25 years
Product Description

Details

Solar panels are made of mono-crystalline or poly-crystalline silicon solar cells, series connection or parallel connection, then hot-pressed and sealed by tempering glass and EVA,TPT, equipped with aluminum alloy frame.

Thicikness
EVA
Tempering glass
TPT
0.4-0.6mm
3.2+/-0.2mm
0.17-0.35mm



Tempering glass

Low iron tempered glass(also named white glass), common thickness 3.2 mm or 4 mm, the transmittance is up to 90% , This glass also resists UV light radiation, and its transmittance is not falling..



EVA

EVA is a kind of hot melt adhesive, the thickness between 0.4 mm - 0.6 mm, smooth surface, uniform thickness



soler cell

Solar cell is the smallest unit of the photoelectric conversion, its working voltage is about 0.5 V,






back veneer

Back veneer is that the protective material of the back of solar panels, including TPT, BBF, DNP, etc.



junction box

Junction box is generally is made of ABS, adding anti-aging agent and resist UV radiation agent.



aluminum alloy frame

frame adopts hard aluminum alloy, thickness of surface oxidation layer is more than 10 micron, it can ensure 25 years'

Advantages

1.China leading solar panel module manufacturer
2.Advanced technology, professional manufacture, and excellent quality.
3.100% A grade cells with ±3% power tolerance range.
4.High module conversion efficiency, low module price
5.Anti-reflective and high viscous EVA
6.High light transmission Anti-reflective glass
7.10-12 years product warranty, 25 years limited power warranty.
8.Strong productive ability and quick delivery.

Applications
Certifications
Company Information
FAQ



Q1. Can I have a sample order for led light?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



Q2. What about the lead time?

A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than



Q3. Do you have any MOQ limit for led light order?

A: Low MOQ, 1pc for sample checking is available



Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.



Q5. How to proceed an order for led light?

A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.



Q6. Is it OK to print my logo on led light product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.



Q7: Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products.



Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
