We adopt Germany technology, carbon fiber far infrared heating system. Each layer has
independent heating system, heat up faster, onLY need 3-5 seconds for 1℃. Turbo blower
ensures hot air to circulate inside the furnace, temperature inside the furnace is equal and
temperature difference does not exceed 2℃. -
.Our glass laminating machine can adopt NEW PVB/TPU/EVA film as interlayer to produce
architectural laminated glass, top grade decorative laminated glass, bulletproof laminated glass,
armored glass, etc. The similar machines from other local suppliers can do EVA glass lamination only. -
We adopt wind-cooling vacuum pump, Italian design, working stable and structure beautiful. It
could continuously work for 24 hours. Vacuum rate reach up to -0.09 — -0.098Mpa. It’s
equipped with vacuum buffer tank, even in case of interruption of electricity supply, the tank
could ensure vacuum for silicone bag and make sure high product yield.
Double vacuum system makes vacuum faster and better. -
Our machine produces curved tempered laminating glass in one step, no need autoclave and
pre-pressing machine. Max bending height reaches 400mm. If you have autoclave, our
laminating glass equipment could work with it to produce curved safety glass easily and
economically. -
PLC control, all program could be completed automatically. Heating time and temperature
could be adjusted according to the glass thickness. Working status could be shown on touch
screen.
6 It adopts silica gel plate which is imported from USA, thick 3 mm, it could stand high
temperature to 180°C. Quality guarantee period keeps 4 years in normal condition. Each layer
silica gel can put glass around 36mm thickness and it improves processing efficiency. Silica gel
plate which produces in domestic factory features aging fast, short life, poor seal and low
vacuum.There is steel mesh on each tray to ensure that small size glass could be processed by our
machine. In each silicone bag, there are 2pcs of teflon mesh to protect silicone bag from being
broken by glass.
