 1. Product introduction

Four-layer automatic laying hen farming equipment can realize raising 30,000-50,000 chickens in a single chicken house with high intensive degree and good economic benefit. It greatly saves labor management cost, construction cost and equipment cost. It is the first choice of large and medium-sized breeding enterprises. Besides meeting the needs of domestic customers, products are continuously exported to Africa, Southeast Asia, West Asia and Oro. Sri Lanka and other countries and regions.

9

2. Product specification

model

tiers

cell size(mm)

cage size(mm)

Birds Qty

L1

3

607*600*420

1215*2160*2700

96

L2

4

607*600*420

1215*2160*3400

128

L3

5

607*600*420

1215*2160*4050

160

L4

6

607*600*420

1215*2160*5380

192

L5

8

607*600*420

1215*2160*6680

256

3. Product feature and application

The structure of the equipment is firm and the design is reasonable. The cage is made of imported alloy material. Its normal service life is as high as 20-30 years. It is not rusty and deformed. The equipment is equipped with automatic feeding system, dung system, egg picking system and environmental control system. This device saves a lot of money and labor, and can create higher benefits for farmers.

4. Production details

1) The cage net is treated by hot dipping zinc with cold drawn wire of different diameters. It has acid, alkali and corrosion resistance. Its service life is more than 15 years. The main body of cage is made of 2mm thick hot-dip galvanized sheet (HANDAN Iron and Steel Company). It has excellent quality, acid, alkali and corrosion resistance, and its service life is more than 15 years. Including XI’AN nipple, white PVC water pipe, German imported ALATEX egg pickup belt, Al-Mg alloy material tank, stainless steel C-nail, 304 stainless steel screw

60

2) Manure cleaning system:Longitudinal transporting head and tailstock and power transmission device adopt 1.5 kW reducer. The surface of driving shaft is covered with glue. The main frame is made of hot-dipped galvanized sheet. The surface of key parts is hot-dipped galvanized. Horizontal cleaning is driven by a high quality reducer, and the two sides of the guard plate are hot dipped with 2.5mm thick steel plate.

2

3) Automatic feeding system:The main frame of each feeder is made of 2.5mm thick galvanized sheet, and the hopper is made of 1mm galvanized sheet.

14

5. Deliver,shipping and serving

1) Deliver time:20-45days

2) Port:Qingdao

3) Serving:

serving

6. FAQ

Q:Can your equipment be customized?

A:Our equipment has two configurations: low and high. We can provide you with the most reasonable and cost-effective equipment according to the size of the chicken house, the amount of investment and the number of chickens.

Q:We have a 5,000 square meters farm with about 10,000 free-range layers. We plan to raise 50,000 chickens in cages instead. Do you have any good suggestions?

A:Our company has 30 years of experience in egg production and processing equipment and 15 years of experience in egg cage. We can give you advice and experience in raising chickens to ensure better benefits.

Q:How long is the service life of your equipment?

A:The service life of cold galvanized cage is 8-12 years and that of hot galvanized cage is 15-25 years.
