BZC600BLBC deep water well drilling machines also known as full hydraulic rig. A rig that uses hydraulic pressure to drive and control all moving parts. This type of drilling rig realizes stepless speed change by high-pressure variable oil pump, which simplifies the transmission mechanism and removes the gear transmission. It not only reduces the weight of the rig but also fully utilizes the power. At the same time, the rig has a high speed, stable operation, convenient and safe operation, easy to realize automation and instrumentation, and is particularly suitable for drilling water borehole.
Product parameters:
|
Technical parameter |
|||
|
Drilling depth（M） |
600 |
||
|
Drilling diameter（mm） |
500 |
||
|
Speed of turntable（r/min） |
117；102；60；38；22；13；16(reverse) |
||
|
Torque of turntable（KN.m） |
5.4----50 |
||
|
Single rope lifting capacity of main windlass(KN) |
50 |
||
|
Maximum lifting capacity of main windlass(KN) |
300 |
||
|
Single rope lifting capacity of assistant windlass(KN) |
60 |
||
|
Maximum lifting capacity of assistant windlass(KN) |
240 |
||
|
The lifting capacity of hook（KN） |
300 |
||
|
Bearing capacity of drilling tower (KN) |
360 |
||
|
The height of drilling tower (mm) |
15519 |
||
|
Drill pipe |
Kelly bar（mm） |
108×108×10500 |
|
|
Assistant pipe (mm) |
.Ф89×10×9000 |
||
|
WB1200/12 |
Diameter of cylinder (mm) |
120 |
|
|
Stroke of piston (mm) |
140 |
||
|
Theoretical flow (L / min) |
1200 970 846 467 |
||
|
Rated pressure (Mpa) |
4.5 5.5 6.5 12 |
||
|
Diameter of suction tube (mm) |
120 |
||
|
Diameter of drain pipe (mm) |
64 |
||
|
Input power (kw) |
110 |
||
|
Truck chassis |
Drive form |
8×4 |
|
|
Engine |
Model |
WP10.270E32 |
|
|
Rated power（KW） |
199 |
||
|
Speed （r/min） |
2300 |
||
|
Size （L*W*H）(mm) |
11510*2480*2800 |
||
|
Electric generator |
Model |
MF |
|
|
Rated power (kw) |
30 |
||
|
Rated voltage(v) |
380 |
||
|
Rated current(A) |
27 |
||
|
Speed (r/min) |
1480 |
||
|
Frequency(Hz) |
50 |
||
|
The highest speed（Km/h） |
70 |
||
|
Weight （kg） |
27500 |
||
|
Transport size（L*W*H）(mm) |
15539×2480×4032 |
||
|
Working size（L*W*H）(mm) |
11145×2480×16765 |
||
Main functions of drilling:
1. Obtain underground physical data and obtain core, cuttings, oil, water, natural gas, etc. from the bottom of the well.
2. As a geophysical logging channel, obtain data on various geophysical fields of the rock formation, such as underground military fire tests.
3. As an artificial channel, observe the mineral, hydrological and geological structures in the stratum.
4. Comprehensive application, comprehensive exploration and acquisition, and the use of underground resources.
Hot Tags: mobile rotary water borehole drilling machine, China, manufacturers, suppliers, factory, price, cheap, for sale
The rig should be checked at any time
1. Check the consolidation of the wire rope end;
The contents of the wire rope inspection are: the number of safety rings of the wire rope, the selection, installation and lubrication of the wire rope, the defect inspection of the wire rope, such as the diameter and wear of the wire rope, the number of broken wires of the wire rope, etc.;
2. Check the pulley system of the drilling machine at any time. The main inspection items are: the condition of the pulley body and the anti-jumping device of the transition pulley;
3. Check the walking system of the drilling rig at any time. The main inspection items are: the condition of the pile machine, the card board and the hook pipe system, and the laying of the sleeper;
Third, do a good job of rig maintenance and repair records, the replacement parts should have a detailed record to ensure that the spare parts are used within the validity period, or keep abreast of the time of the next replacement;
4. If the rig is faulty, stop the operation immediately and do not use it until the fault is not eliminated.
